Characteristics of Colorlight 5A LED Display Receiver Card:
Superior display quality: high refresh rate, high color depth, and high brightness with the conventional chips. Supports all types of display module of the mainstream products (5A means any row, било коју колону, any scan, any chips, and any shape).
The use of more advanced algorithms, so that the receiving card to maximize the use of resources in order to improve display quality.
Supports for high-precision pixel-by- pixel calibration in the Brightness and the chromaticity.
Support for large area display.
Professional design and strict testing to ensure high quality and reliable.
Supports all conventional sending card of ColorLight, such as T7 LED sender, Q7 HD transmitter, Gigabit NIC, DMB, итд.
Specifications of Colorlight 5A LED Display Receiver Card:
|
Параметерс |
RA5 |
|
Board size |
Length 143mm, width 93mm |
|
Потрошња енергије |
3В |
|
Current |
0.6А |
|
Улазни напон |
DC 5V±10% |
|
Радна температура |
-30℃~85 |
|
Transportation temperature (storage level) |
-50℃~125
|
|
Тежина |
100г |
|
Antistatic ability |
2КВ |
|
Module specification |
Any row, било коју колону у склопу 8192 пиксела |
|
Scanning mode |
Any scan from Static до 1/32 скенирати |
|
Chip support |
Conventional chip |
|
Module pumping-point |
Nonsupport |
|
Серијски пренос података |
Nonsupport |
|
HUB board data exchange |
Nonsupport |
|
Grey-scale |
1 -65536 |
|
Серијска фреквенција |
1KHz~41.3Mhz |
|
Контролна област (single card) |
Колор ,1/8 скенирати : 512*128 |
|
Correction area (single card) |
256*256 пиксела |
|
cascade card numbers (single cable) |
65536ПЦС |
|
The communication distance between the key controller and the card, the card and the card |
CAT5 cable??40М CAT6 cable??70М Optical cable??0М |
|
Cascade control area |
65536*65536 пиксела |
|
Фресх рате |
Related to scanning mode, статична : 64×64module, 4096 grayscale: 4000Hz in maximum |
|
Sending equipment |
Sending card or gigabit NIC |
|
Temperature sensor |
Without |
|
Relay |
Without |
|
Network upgrade |
Подршка |
|
Размена мрежних портова |
Подршка |
|
Double backup |
Подршка |
|
Virtual pixel |
Nonsupport |
|
Compatible transmission equipment |
Гигабитни прекидач, gigabit optical fiber converter |
